4/29/2014

crate mould

Taizhou Huangyan Micon Plastic Mould Co., Ltd. is a professional manufacture specialized in design and development of plastic molds.The main products are thin wall container mould, household mould, commodity mould, medical mould, backet mould, industrial mould, plastic furniture mould...

crate mold, spare parts box mold, storage box mold, tool box mold

Core & Cavity Steel: P20, 718, 2738, H13 etc or according to customer's require.
Plastic material: PP, PE or according to customer's order .
Mould base: 45# (>30HRC) or LKM
Cavity:1 / 2
Rnuuer: hot runner
Mould Life: More than 1 million shots
Specification: All size of available
Design Software: UG, CATIA, PROE, OUT CAD

http://www.miconmould.com/Crate-mould.html
http://www.plasticmold.org/Crate_Mould.htm






household mold, commodity mold

Taizhou Huangyan Micon Plastic Mould Co., Ltd. is a professional manufacture specialized in design and development of plastic molds.The main products are thin wall container mould, household mould, commodity mould, medical mould, backet mould, industrial mould, plastic furniture mould...

household mold, commodity mold, kitchenware mold, plastic furniture mold, sanitaryware mold

Core & Cavity Steel: P20, 718, H13 etc or according to customer's require.
Product material: PP / PS / PE / ABS / POM etc or according to customer's require.
Mould base: 45# or LKM
Cavity: 1 / 2 / more
Rnuuer: hot runner / Cold runner
Mould Life: More than 1 million shots
Specification: All size of available
Design Software: UG, CATIA, PROE, OUT CAD

http://www.miconmould.com/Household-mould.html

http://www.plasticmold.org/Commodity_Mould.htm






measuring cup mold, medical cup mold

Taizhou Huangyan Micon Plastic Mould Co., Ltd. is a professional manufacture specialized in design and development of plastic molds.The main products are thin wall container mould, household mould, commodity mould, medical mould, backet mould, industrial mould, plastic furniture mould ...



Core & Cavity Steel: 2316, S136, H13 etc

Product material: PP / PS
Mould base: P20 or LKM
Cavity: 2 / 4 / 6 / 8 / 16
Thickness: 0.4--0.6MM
Rnuuer: hot runner
Mould Life: More than 3 million shots
Specification: All size of available
Design Software: UG, CATIA, PROE, OUT CAD

http://www.miconmould.com/Labware-Medical-mould.html







food container mold, thin wall mold

Thin wall mold, thin wall mould, food container mould

Taizhou Huangyan Micon Plastic Mould Co., Ltd. is a professional manufacture specialized in design and development of plastic molds.The main products are thin wall container mould, household mould, commodity mould, medical mould, backet mould, industrial mould, plastic furniture mould...

thin wall mold,  food container mold, food box mold, microwave container mold

Core & Cavity Steel: 2316, S136, H13 etc
Product material: PP / PS
Mould base: P20 or LKM
Cavity: 1 / 2 / 4
Thickness: 0.4--0.6MM
Rnuuer: hot runner
Mould Life: More than 3 million shots
Specification: All size of available
Design Software: UG, CATIA, PROE, OUT CAD

http://www.miconmould.com/Thin-wall-mould.html

http://www.plasticmold.org/Thin_Wall_Mould.htm









bucket mold

Taizhou Huangyan Micon Plastic Mould Co., Ltd. is a professional manufacture specialized in design and development of plastic molds.The main products are thin wall container mould, household mould, commodity mould, medical mould, backet mould, industrial mould, plastic furniture mould...

bucket mold, pail mold, tub set mold, injection molding

Core & Cavity Steel: P20, 718, H13 etc
Product material: PP / PE
Mould base: 45# or LKM
Cavity: 1
Rnuuer: hot runner / Cold runner
Mould Life: More than 2 million shots
Specification: All size of available
Design Software: UG, CATIA, PROE, OUT CAD

http://www.miconmould.com/Bucket-Pail-mould.html
http://www.plasticmold.org/Bucket_Mould.htm





4/28/2014

mould maker--Micon mould


Micon Mould is dedicated in plastic mold maker. We offer high quality moulds with competitive cost. Our strength is in making thin wall mold, food container mold, cutlery mold, household mold, medical mold, industrial mold ...

http://www.mould-maker.com
http://www.miconmould.com












thin wall container mould maker







Thin wall container is very popular in market all over the world. (Thin wall container is generally refers to the container which wall thickness is about 0.4mm-0.6mm) .

Since the molds will be operated in high speed injection machines, shorter cycle times means higher productivity and lower costs per part. so it requires a very good cooling system and high hardness in order to ensure the short cycle and the mold life. In China, Micon Mould has rich experience in thin wall mold making.

The following industries make use of thin wall molding:

A.food packaging ( e.g. food containers and lids)
B.medical (e.g. syringes)
C.mobile telecommunications (e.g. mobile phone housings)

The plastic melt material used in thin wall products have PP,PS,PE,PTE and PC etc. The trend towards thin wall molding continues to increase in many plastic industries as plastic material and energy costs continue to rise and delivery lead times are squeezed.

As to thin wall mould, the mould dimension should be controlled precision. For such product, we always use high speed milling machine and some other high precision tooling machine to tool it, the dimension tolerance should be controlled in 0.05mm.
Regarding the ejector system for thin wall container mould, we usually use air to blow first, let the container not stick to the core and then use double ejector plates drived by hydraulic cylinders to ejector the product off the mould. As the container is too thin, so we generally don��t use ejector pins, because ejector pin will easy lead to product deformation.
Cooling system is also very important to such thin wall product, just as I stated above, for such product molding, it needs high speed and high pressure. So the mould temperature will be high, it is very important to control the mould in low temperature, so we should add water channel as more as possible, and it should be near the product surface. Besides, we always adapt with BeCu to help the mould cooling, because BeCu has good thermal conductivity. Even though, the price will be much high than mould without BeCu, but the good cooling will help make the product very beautiful.

China Mold Maker

Micon Mould is a China plastic mold making company, a professional plastic mold maker. It began as a small tool workshop which was set up in 2008 in Huangyan which is known as China plastics and mold making industry city. With convenient traffic to Ningbo and Shanghai port.
Micon Mould manufactures plastic injection molds and has ability to make plastic product design and mold structure design for many plastic products. The molds are supplied to many countries as well as inland China. The kinds of molds that are designed and manufactured are broadly classified in five types based on their usage. These are:


.Thin Wall Mold
.Package Mold
.Commodity Mold
.Medical Labware Mold
.Industrial Mold
.Home Appliance Mold

Among those, we have rich experience and concentration on the followings:
Thin wall moldmaking, thin-walled container mold, thin-walled cup mold, thin-walled tub mold etc.
Bucket mold making,0.5L-20L capacity with shapes of round, rectangular or square.
Crate mold making, retail crate mold, dairy crate mold, beverage crate mold, bread crate mould, meat crate mould, argriculture crate mold etc.
Horticulture mold making, planting growing pot mold, yard fence mold, propagation tray mold, watering can mold etc.
Medical mold making, petri dish mold, test tube mold, medicine measuring cup mold, medical use trays mold
Pursuing excellence and making cost-saving molds at Micon Mould. Our team consists of professional and passionate sales, skilled desingers, experienced mold makers and machine operators. We use the best machines available for mold making most for which are imported from various part of the world. These machines operate on 24 hours and at very high speed as well as give high precision (accuracy) rate. The 5 axis CNC machines are used as the main processing machines. At Micon Mould, it is believed that most efficient results are achieved by using latest technology and up to date methods. We provide 3D printing prototype service as customer required.

http://www.miconmould.com http://www.mould-maker.com
miconmould@gmail.com

Huangyan Micon Mould Co.,Ltd.--Huangyan Introduction

Micon Mould is situated in Huangyan, which is famously known as"the Town of China Mould". It's a short commute from Huangyan to Ningbo, Wenzhou, Hangzhou or Shanghai. It is a district affiliated to Taizhou City, Zhejiang Province.

Micon Mould has many years of experience on the research, design, manufacture and sale of plastic mould. with years of development, we has formed its own characteristic in mould design and manufacture. our factory is the specialized injection mold manufacturer, mainly design and make the moulds of:  Thin wall mold, household mold, medical mold, industrial mold, commodity mold, plastic mold, injection molding.


Mould Industry in Huangyan started in the middle of 1950's in China, it is China National Torch Program Base which grows fast in recent years. Thousands of mould manufacturers spread over Huangyan district, offering tremendous moulds for home and abroad.
The moulds mainly include: plastic mould, injection mould, commodity mould, home appliance mould, PET mould, automotive mould and extrusion mould.

How to go to Huangyan?
By Air: Take flight from Beijing to Taizhou; Shanghai to Taizhou; Guangzhou to Taizhou, Shenzhen to Taizhou etc. It takes about one hour from Taizhou airport to Huangyan district.
By Train: Take express train from Hangzhou to Taizhou, 2 hours; Shanghai to Taizhou, 5 hours; Ningbo to Taizhou, 1 hour etc.
By Road: Informed contact person and pick up you in Shanghai airport, Hangzhou airport, Ningbo airport etc.
Hotels in Huangyan?
Huangyan Yaoda Hotal ( 5 star)
International Hotel
Romantic Hotel
Green Hotel

http://www.miconmould.com
miconmould@gmail.com
